FAIRINO FR20 - COBOT
COBOTS - The FR20 collaborative robot (cobot) is a powerful, scalable, and sustainable robotic arm designed to empower both integrators and end-users. Engineered to tackle industry challenges, the FR20 provides an innovative solution to overcome key automation pain points. Leveraging FAIR's advanced technology in intelligence and flexibility, along with self-developed core components, this cobot offers unmatched versatility.
The FR20 cobot transcends traditional boundaries in intelligent and flexible robotic applications, seamlessly adapting to diverse scenarios and providing an ideal platform for customized solutions. Its robust performance and adaptability make it the perfect choice for companies seeking high-performance, scalable cobot solutions for complex, real-world applications.
Price:
$15,499.00
MTTR :
(Mean Time To Repair)
30,000 HR.
Payload
20KG
Reach
1854mm
Repeatability
±0.1mm
Engineered to be one of the most robust cobots on the market, the FR20 rivals equipment costing up to 5× more—without sacrificing performance. See how this six-axis, 20 kg-payload arm is transforming intelligent manufacturing with flexible, efficient, and collaborative automation that elevates productivity and innovation.
COMPARE (Ours vs. Theirs)
FAIRINO FR20 | UR20e – Universal Robots |
Price: $15,499.00 | Price: $62,990.00 |
Manufacturer Warranty: 18 Months | Manufacturer Warranty: 15 Months |
Expected Lifetime: 50,000 Hrs | Expected Lifetime: 35,000 Hrs |
After Sales Support: 5 Years (US Based) | After Sales Support: 5 Years (US Based) |
Payload: 20 kg | Payload: 20 kg |
Reach: 1854 mm | Reach: 1750 mm |
Degrees of Freedom: 6 axes | Degrees of Freedom: 6 axes |
Pose Repeatability (ISO 9283): ±0.03 mm | Pose Repeatability (ISO 9283): ±0.05 mm |
Typical TCP Speed: 2 m/s | Typical TCP Speed: 1.5 m/s |
IP Classification: IP54 | IP Classification: IP54 |
Noise: < 65 dB | Noise: < 65 dB |
I/O Ports: Digital Input (DI): 2, Digital Output (DO): 2, 2 Analog Input (AI), 2 Analog Output (AO), 2 High-Speed Pulse Input | I/O Ports: 2 Configurable Digital Inputs/Outputs, Analog I/O Ports RS485 for communication |
Tool I/O Power Supply: 24V DC | Tool I/O Power Supply: 24V DC |
Footprint: 240 mm | Footprint: 245 mm |
Weight: 75 kg | Weight: 64 kg |
Operating Temperature: 0–45 °C | Operating Temperature: 0–50 °C |
Operating Humidity: 90 % RH | Operating Humidity: 90 % RH |
Materials: Aluminium, Steel | Materials: Aluminium, ABS Plastic |
